LM319 ICs. 14pin DIP, High Speed Dual Comparator (pack of 5 ICs)

Click here for online purchasing and delivery information >>


 LM319 High Speed Dual Comparator IC's, 14pins DIP case.
Manufactured by Signetics

Pack containing: Five IC's



To download a full datasheet click here.



Features
• Operates from a single 5V supply
• Typically 80ns response time at ±15V
• Open collector outputs : up to + 35V
• High output drive current : 25mA
• Inputs and outputs can be isolated from system ground
• Minimum fan-out of 2 (each side)
• Two independent comparators


Description
The LM319 is a dual high speed voltage comparator designed to operate from a single + 5V
supply up to ±15V dual supplies. Open collector of the output stage makes the LM319
compatible with RTL, DTL and TTL as well as capable of driving lamps and relays at currents
up to25mA. Typical response time of 80ns with ±15V power supplies makes the LM319 ideal
for application in fast A/D converts, level shifters, oscillators, and multivibrators.
